How to measure the sliding door of the wardrobe
When customizing or replacing wardrobe sliding doors, accurate measurements are a key step to ensure the perfect installation of the door. Whether it is on-site woodworking or online shopping for finished sliding doors, mastering the correct measurement method can avoid the trouble caused by dimensional errors. The following is a structured guide on wardrobe sliding door measurement in a popular topic on the Internet in the past 10 days, including detailed steps and precautions.
1. Preparation before measurement
1.Tool preparation:Tape measurement (metal material is recommended), paper and pen, and level (optional).
2.Clean up the space:Remove debris around the wardrobe to ensure the measurement area is accessible.
3.Confirm track type:Understand in advance whether the sliding door track is a top rail, ground rail or a dual-rail design, and the measurement requirements of different tracks are slightly different.
| Measurement items | Key points of operation | Common Errors |
|---|---|---|
| width | Measure the upper, middle and lower parts of the cabinet opening and take the minimum value | Uneven walls or tilt cabinets are not considered |
| high | Measure the left and right sides and the middle positions to get the maximum value | Ignore gaps on floors or ceilings |
| depth | Distance from back plate to rail mounting surface | The sliding door thickness is not deducted (usually 5cm reserved) |
2. Detailed measurement steps
1. Width measurement:
- If it is a single door: directly measure the inner diameter of the cabinet opening.
- If it is multiple doors: the total width needs to be divided by the number of door leaves, and the overlapping part is reserved (usually each door overlaps 2-3cm).
2. Height measurement:
- The vertical distance from the ground to the top of the track must be deducted from the thickness of the floor material (such as ceramic tile, carpet).
- If it is a hanging rail sliding door, the height needs to be added to the adjustment space of 1-2cm.
3. In-depth confirmation:
- The depth of the standard wardrobe is 60cm, and the thickness of the sliding door is usually 3-5cm. It is necessary to ensure that the cabinet depth is ≥55cm.
| Sliding door type | Width recommendations | Highly recommended |
|---|---|---|
| Single sliding door | ≤100cm | |
| Double sliding door | Each fan is 60-80cm |
3. Answers to popular questions (high frequency searches in the past 10 days)
Q1: How to adjust the measured value when the wall is uneven?
- It is recommended to use a level instrument to detect. If the error is > 5mm, the difference should be reduced in the tilt direction.
Q2: Do I need to reserve installation gaps when shopping for online sliding doors?
- Usually, the width needs to be reduced by 3-5mm and the height needs to be reduced by 5-10mm (the specific requirements shall be subject to the merchant’s requirements).
Q3: Can I use the original size directly when replacing the old door?
- Remeasurement is required! Old cabinets may be deformed, and new track standards may be different.
4. Things to note
1.Multiple reviews:Measure at least 2-3 times to avoid human error.
2.Photo record:Take panoramic views and details of the cabinet to facilitate communication with merchants.
3.Consult professionals:If non-standard sizes are involved (such as curved tops and oblique walls), it is recommended to contact customization services.
With the above structured data and steps, you can easily complete the precise measurement of the sliding door of the wardrobe. For further reference, you can compare the official measurement guides of recent popular brands (such as Sofia and Oppein), or watch the actual test tutorials on short video platforms.
