Wooden Door/Wooden Floor/ Furniture UV Paint Double UV Lamps Dryer Equipment
Tuogao Development Co., Ltd.- Type：UV Dryer
- Driven Type：Electric
- Automatic Grade：Automatic
- Packaging Material：Wood
- Packaging Type：Case
- Application：Paint, Furniture
Base Info
- Model NO.：DR-SD02
- Certificate：Ce,ISO
- Power：380V 50,60Hz
- Warranty：1 Year
- Feeding Mode：Manual
- Industry Application：Furniture
- After-Sale Service：Support Overseas Service
- Transport Package：Wooden Case
- Specification：see below
- Trademark：DingRan
- Origin：Yixing
- HS Code：8543709990
- Production Capacity：50000sets,Year
Description
Dimensions
Product Information:
1. Conveyor belt use longer pin chain aluminum tube body, transmission smooth, not
wandering; Japan UCF 207 bearing;
2. Equipped with high accuracy Germany Siemens reduction motor,Taiwan Delta
frequency inverter.
3. Equipped with domestic brand light source 9.6kW transformer , high quality
capacitance,imported high quality mercury lamp, size20*1388mm,lifetime 1300-1500H
4. Heat dissipation system use the centrifugal fan DF-190-0.75kW,equipped with
aluminum lamp shape, have a good heat dissipation.
5. The total bracket is welded by 3mm steel material, steadily.
6. Equipped with separately lamp cabinet, with the translucent window, it's easy to
observe the working situation, and also equipped with the separately fan, passive air
input system on the side, and the active air input system on the bottom.
7. Separately UV lamp, separately ammeter, it's easy to observe the working situation.
8. Equipped with Schneider electrical parts.
FAQ:
Q1: What's the warranty of the machine?
The machine warranty is 1 year.
Q2: How about the service?
Engineers available to service machinery overseas. And the part of the machine, we
can also DHL to you.
Q3: How to contact us?
Tel: +86- 18857104505
Q4: Why choose the DingRan Machinery CO.,LTD.?
DingRan Machinery CO.,LTD is a professional factory in coating industry, and we
have many years experiences in this field.
In our factory, we have about 2000m2 sample room, we can make the samples
directly according the customer's requirement due to we combine the UV paint factory
in the same industry zoon.
Q5: Where is our market?
Our main market is Europe and American, such as French and USA have our
customer. Some of machines have CE certifications, it's no problem to sale in Europe.
Also, the Southeast Asian is our market, such as India, we are developing and will
enlarge it in the next years.
Q6: How to choose the right machines?
The customer can bring the samples to our factory, we can find the suitable paint
immediately, and make the samples in our machines directly. Then our customer will
have the right solution how to coat and know what machine is available for their
products.
Thank you for time!
