Ntek Yc6090 Small Format UV Flatbed Printing Machine Wood Printer
LINYI WIN-WIN MACHINERY CO., LTD.- Plate：Digital Printing
- Structure：Flat-Bed Cylinder Press
- Color & Page：Multi-Colour Printing Press
- Usage：Glass, Ceramic, Acrylic, Wood, PVC, Ect...
- Automatic Grade：Semi-Automatic
- Printing Interface：USB2.0
Base Info
- Model NO.：YC6090
- Printing Speed：3-12sqm,H
- System Supported：Windowsxp32
- Transport Package：Plywood Cases
- Specification：1260*2250*1360mm
- Trademark：Ntek
- Origin：Shandong, China
- HS Code：8443322100
- Production Capacity：800 Sets,Year
Description
Product Model
YC6090
Printhead Technology
Drop-on demand piezo electric
Printhead Control
Printhead voltage is software adjustable
Printhead Type
EPSON DX5/DX7/XP600/TX800/RICOH GH2220
Printhead Number
2-4heads
Ink Characteristics
UV Curing Ink
Ink Reservoirs
Refillable on the fly while printing/1000ml per color
LED UV Lamp
More than 20000-hours life
Color Control
ICC based color, curves and density adjustment
Printhead Arrangement
CMYKW varnish optional 3-12sqm/h
Cleaning System
Positive Pressure Cleaning
Guide Rail
Taiwan HIWIN
Working Table
Vacuum Sucking/ Glass Table
Printing Size
900*600mm
Print Interface
USB2.0/USB3.0/Ethernet Interface
Media Thickness
0-100mm, higher can be customized
Print Resolution
360*1080dpi, 720*720dpi, 720*1080dpi,720*1440dpi
Life of Printed Image
3 years(outdoor),10years(indoor)
File Format
TIFF,JPEG,Postscript3,EPS,PDF etc.
RIP Software
UltraPrint/ Photoprint optional
Power Supply
220V 50/60Hz(10%) >15A
Powder
3100W
Operation Environment
Temperature 20 to 28ºC, Humidity 40% to 60%
Machine Dimension
1060*2100*1160mm
Packing Dimension
1260*2250*1360mm
Weight
400kg
Warranty
12 Months exclude the consumables
Printing Sample:
CMYK+W+V All three colors at onceThe use of gloss oil makes the product more gorgeous gloss and "high gloss" effect, not only makes the surface
of the whole picture has a gloss sense, get a more exquisite printing effect, but also can better protect the coating,
make the product more durable.
Company Information:
Linyi Win-Win Machinery Co., LtdLinyi Win-Win Machinery Co.,Ltd is founded in 2009 in Shandong, China, is a high-tech machinery manufacturer, integrated with
the R&D, production, sales and maintenance in a whole. We mainly manufacture large format UV printers and OEM service is available.
We have 13 years experience in producing and exporting UV printers. The factory covers more than 20,000 square meters, with six
professional production lines, mainly produce UV flatbed printer, UV flatbed and roll to roll printer and UV hybrid printer. With high
quality, our printers are welcome more than 150 countries in Asia, Europe, Australia and Africa etc., and OEM service is available.
The UV printer can widely print on glass, ceramic tile, PVC ceiling, aluminum sheet, wood MDF board, metal panel, billboard, acrylic
panel, paper board, foam board, PVC expansion board, corrugated cardboard, bamboo fiber board etc; and for flexible materials such
as PVC, canvas, leather etc., and widely applied in decoration industry, glass industry, advertising&signs industry, leather, furniture
and ceramic industry etc. All our printers are with CE certificate.
FAQ: 1.How long does the printing images will last outdoors and indoor?
The printing images can last at least 3 years outdoors, and more than 10 years indoor.
2. How about the stability and quality of the printing images?
This UV flatbed printer can used to print on most of medias with best quality, durability,best result.
3. How about the maintance and aftersales service?
Our engineer available service overseas, and we can provide remote control service and online service for customers.
But costomer has to be responsible for the accommodation and transportation costs of the technical staff.
4.Are you a manufacturer or trade agent?
We are the manufacturer of Uv flatbed printers.
5. Is there any guarantee for this printer?
Yes, we have guarantee for the printer. We provide one year warranty for all the electronic parts including the
main board, driver board, control board, motor, etc. But there is no warranty for wearing parts like ink pump,
printhead, ink filter, and slide block since they are consumables.
6. How can I install and start to use the printer?
At first, you should read the users' manual to understand the machine and watch the video. After you get the
machine, our technician will teach you how to install and use-machine by remote control via Teamviewer or Skype.
Whenever you have questions to the machine, you can contact our technician or me.
7.Can I get supplies and wearing parts from you?
Yes, we provide all the wearing parts for our printers always and they are in stock.
8. How will you achieve the warranty?
If any electronics or a mechanical part is confirmed to be broken, Ntek should send new part within 48hours by
express like TNT, DHL, FEDEX etc to the buyer. An shipping cost should be born by the buyer.
9. What kinds of materials need premier before printing?
Glass, ceramic, metel, acrylic
