• Model NO.：D180S
• Standard：Chinese Standard
• Remote Control：Without Remote Control
• Door Width：1200mm
• Door Weight：120~180Kg
• Usage：Market, Fire Exits, Home, Hotel, Office, Hospital, School
• Color：Silver
• Finish：Mirror
• Packing：Packing
• Feature：Safe
• Protection Level：IP68
• Transport Package：Standard Carton Box
• Specification：320x110x70mm
• Trademark：S4A
• Origin：China
• HS Code：8302600000
• Production Capacity：200000,Mouth

Basic Info.

Model NO. D180S Standard Chinese Standard Remote Control Without Remote Control Door Width 1200mm Door Weight 120~180Kg Usage Market, Fire Exits, Home, Hotel, Office, Hospital, School Color Silver Finish Mirror Packing Packing Feature Safe Protection Level IP68 Transport Package Standard Carton Box Specification 320x110x70mm Trademark S4A Origin China HS Code 8302600000 Production Capacity 200000/Mouth

Product Description

Floor Mounted Concealed Door Closer for 180 kgs Entry Commercial Wooden/Glass Gate/Door

Model No.: D180S



What is Floor Concealed Door Closers?

The overhead or floor mounted concealed door closer is a very common type of door closer mechanism which is normally unseen and unnoticed. ... Some concealed closers only allow single directional control for opening and closing to a fixed point or door stop.



Maximum door weight	180kg
Maximum door width	1200mm
Maximum torque	165Nm
Noise	<60dB
Opening and closing time	6-12S
Open range	86°~95°
Power supply	AC220V ±10% 50/60Hz
Rated power	55W
Special machine power	<2W
Operating temperature	-20°C~55°C
Protection level	IP68
Control box size	156x120x46mm
Unit size	320x110x70mm
Unit weight	5.5kg
