• Model NO.：DH-005
• Usage：Normal Door, Fire Door, Glass Door
• Customized：Non-Customized
• Transport Package：Standard Carton
• Specification：118x80x55mm
• Trademark：S4A
• Origin：China
• HS Code：8302410000
• Production Capacity：20000pieces Per Month

Basic Info.

Model NO. DH-005 Usage Normal Door, Fire Door, Glass Door Customized Non-Customized Transport Package Standard Carton Specification 118x80x55mm Trademark S4A Origin China HS Code 8302410000 Production Capacity 20000pieces Per Month

Product Description

Magnetic Door Holder for Glass door

Work with all Kind of  Single & Double Smokeproof Doors

Magnetic door holders are used in rire protection doors, These holders keep the doors open during dap to dap operations When smoke is detected the fire alarm transmit a signal which cuts off the power feed and the mechanism releases the door. This avoids rire and smoke expansion.


Dimensions	118x80x55mm
Holding Force	60kg(110Lbs)
Voltage	12V (24V customized)
Current Draw	12V/160mA     24V/80mA
Suitable for	All Kind of  Single & Double Smokeproof Doors
Surface Temp	≤20ºC
Operating Temp	-10ºC~55ºC(14°F-131°F)
Suitable Humidity	0~90%(relative humidity)

1. How to Install Magnetic Door Holder?
There are several types of magnetic door holders. You can place most door holders near the bottom or top of a door. Some models can be mounted on the floor. Door stops can be used in office or retail buildings and warehouses where a door needs to be kept open so traffic can pass in and out.
Many are designed to hold self-closing doors and have powerful magnets.
What you need is: door holder kit, a drill, and a pencil to complete this simple task.

2. how to test the Magnetic door holder?
Swing the door back until the door piece and the wall piece connect. Let go of the door handle.
The magnets should hold the door in place if they are lined up correctly.
The low power consumption,Highlights it more environment friendly and more durable. Professional anti-residual magnetism design ensures highest security.
It will release automatically the fire door when fire alarms.It also contains build-out release button for testing and build-in MOV which reverse current protection.
