Automatic Electrical Driven Spray Guns Coating Machine for Wooden Door
Tuogao Development Co., Ltd.- Type：Spraying Machine
- Driven Type：Electric
- Automatic Grade：Automatic
- Packaging Material：Wood
- Packaging Type：Case
- Application：Paint, Furniture
Base Info
- Model NO.：DR-PT01
- Certificate：Ce,ISO
- Power：380V 50,60Hz
- Warranty：1 Year
- Feeding Mode：Manual
- Industry Application：Furniture
- After-Sale Service：Support Overseas Service
- Transport Package：Wooden Case,Shrink
- Specification：see below
- Trademark：DingRan
- Origin：Yixing
- HS Code：8424300000
- Production Capacity：50000sets,Year
Description
Dimensions
Product Information:
1. Equipped with high-strength conveyor belt, which is superior corrosion resistance for
acid, alkaline paints such as PU, AC and NC.
2. Equipped with the sensors to detective the work piece size, and equipped with U-
shaped anti-offset grooves, which can make the conveyor belt run smoothly and never
go wrong;
3. Equipped with the frequency converter to control the transport speed;
4. Two sets of moving gun brackets, opposite distribution installation; each bracket can
install four guns, each gun can be adjusted the paint usage and the coating angel,
controlled separately, makes more working mode for the coating work;
5. Equipped with one set of circulating oil circuit;
6. Equipped with a separate compressed air control unit and built-in filter to ensure clean
and dry air;
7. Equipped with the paint recycle system, includes double roller to collect the paint on the
belt and transport to the paint tank, 99% paint on the belt can be re-collected;
8. Equipped with the exhaust fan which is located at the top of the spray room, controlled
by the frequency converter, it can control the wind speed.
9. The sparying gun support two groups with two-way mode, press 2+2 spraying gun
system, spraying effective for the different work picec in different angle, also equipped
with one set of piston pump in oil supply system.
10. Spraying driving device adopts Japanese servo motor for precise driving, ensure the
spray accuracy.
11. Equipped with the cycling oil system, ensure the constant pressure in spraying gun,
the painting flow is controlled by regulating valve.
12. The air intake system equipped with the double-layer filtering device, ensure clear air
was supplied, the filtering device in exhaust pipe will filter the painting mist.
FAQ:
Q1: What's the warranty of the machine?
The machine warranty is 1 year.
Q2: How about the service?
Engineers available to service machinery overseas. And the part of the machine, we
can also DHL to you.
Q3: How to contact us?
Tel: +86- 18857104505
Q4: Why choose the DingRan Machinery CO.,LTD.?
DingRan Machinery CO.,LTD is a professional factory in coating industry, and we
have many years experiences in this field.
In our factory, we have about 2000m2 sample room, we can make the samples
directly according the customer's requirement due to we combine the UV paint factory
in the same industry zoon.
Q5: Where is our market?
Our main market is Europe and American, such as French and USA have our
customer. Some of machines have CE certifications, it's no problem to sale in Europe.
Also, the Southeast Asian is our market, such as India, we are developing and will
enlarge it in the next years.
Q6: How to choose the right machines?
The customer can bring the samples to our factory, we can find the suitable paint
immediately, and make the samples in our machines directly. Then our customer will
have the right solution how to coat and know what machine is available for their
products.
Thank you for time!
