Zxx-C1812 Mini Waterjet CNC Glass Cutting Machine for Kitchen Cabinet Handle
Linyi All-Need Machinery Co., Ltd.- After-sales Service:24 Hours Online
- Warranty:One Year
- Application:Glass
- Process Usage:CNC Non-Conventional Machine Tools
- Movement Method:Linear Control
- Control Method:Semi-Closed Loop Control
Base Info
- Model NO.:ZXX-C1812
- Numerical Control:CNC,MNC
- Processing Precision:0.05-0.1(mm)
- Performance Classification:High-End CNC Machine Tools
- Certification:CE
- Condition:New
- Product:Mini Waterjet CNC Glass Cutting Machine for Kitch
- Fuction:Open Slot, Notching, Make Holes, Grinding, Cutting
- Models:Different Models as Per Customer Size
- Thickness:3-25mm
- Drawing:CAD Drawing
- Control System:CNC, Servo
- Heads Number:2
- Power:7.3kw
- Weight:1800
- OEM:Offered
- Transport Package:Standard Export Package
- Specification:3100*1600*1560mm
- Trademark:ZNXU
- Origin:China
- HS Code:8464901900
- Production Capacity:20sets,Month
Description
Basic Info.
Model NO. ZXX-C1812 Numerical Control CNC/MNC Processing Precision 0.05-0.1(mm) Performance Classification High-End CNC Machine Tools Certification CE Condition New Product Mini Waterjet CNC Glass Cutting Machine for Kitch Fuction Open Slot, Notching, Make Holes, Grinding, Cutting Models Different Models as Per Customer Size Thickness 3-25mm Drawing CAD Drawing Control System CNC, Servo Heads Number 2 Power 7.3kw Weight 1800 OEM Offered Transport Package Standard Export Package Specification 3100*1600*1560mm Trademark ZNXU Origin China HS Code 8464901900 Production Capacity 20sets/MonthProduct Description
Description | unit | parameter |
Model No. | ZXX - C1812 | |
Colum | Set | Heavy iron |
China | ||
Control System | set | Leetro |
Axis | PC | Cutter change : by hand |
Diam:¢125 | ||
coller:cool water | ||
RPM:42000 RPM 2800 | ||
POWER:1.5KW 4.5KW | ||
Drive | set | YMPC |
Invertor | kw | BEST : 11KW |
Work table size | mm | 1800*1200MM |
Max Process Glass | mm | 1400*1000mm |
Z-axis space height-open | mm | 380 |
motor | set | China |
Internal of machine structure | set | Half cover/ waterproof design |
Work table load weight | KG | 120 |
Positioning accuracy | mm | 0.01 |
Repeated positioning accuracy | mm | 0.01 |
Cutting speed | M/MIN | 0-2M/MIN |
Grinder speed | M/MIN | 0-12M/MIN |
Stroke protection | PC | Omron,Japan |
GEAR | PC | GERMAN DMJ-1.5M High precision |
Limit switch | CHIIB | |
Guide Screw bearing | PC | HIWIN |
Model: Z axis with diagonal contact | ||
Lubrication system | set | Origin : |
Lubrication automatically | ||
Cooling type | set | Water pump |
Main axis cooling | set | Automatic thermostat cooler |
Main electric | CHNT/Schneider | |
Volt./Frequecny | KW | AC/380v/10KW/50HZ (AS PER CUSTOMER REQUEST) |
Machine Size | mm | 1900x2700x2300mm |
weight | KG | 1600 |
power | KW.H | 11.1 |
