• Model NO.：SD105H,155H,215H,305H,350H,450H,550H,650H
• Temperature Type：Single-temperature
• Defrost Type：Frost-Free
• Function：Freezing
• Certification：CE, ISO, ETL
• Transport Package：Package Carton
• Origin：China
• HS Code：8418500000
• Production Capacity：50000sets,Year

Basic Info.

Model NO. SD105H/155H/215H/305H/350H/450H/550H/650H Temperature Type Single-temperature Defrost Type Frost-Free Function Freezing Certification CE, ISO, ETL Transport Package Package Carton Origin China HS Code 8418500000 Production Capacity 50000sets/Year

Product Description

Display Freezer Specification
Top visible glass design
Refrigerant: R600a/R290/R134a
Temperature range: ≤ - 18ºC
Foaming agent: C-P
Climate class: 4
Low-e frameless glass door on top
Molded recessed handle
Mechanical temperature control
Replaceable gasket
4 adjustable feet or 4 rollers
Optional features:
-- Light on lids frame
-- Thermometer

#	Technical Data	SD105H	SD155H	SD215H	SD305H	SD350H	SD450H	SD550H	SD650H
1	Gross capacity  liters	101	155	201	257	304	383	473	567
2	Thickness of  foaming  mm	65	65	65	70	70	70	70	70
3	Basket qty & width in mm	1*195	2*195	3*195	4*205	3*245	4*245	5*245	6*245
4	Unit dimension (w*d*h)  mm	545*580* 850	735*580* 850	895*580* 850	1125*580* 850	1035*750* 850	1275*750*850	1535*750*850	1805*750* 850
5	Packing dimension   mm	555*585* 880	745*585* 880	905*585* 880	1160*625* 880	1080*760* 890	1320*760*890	1580*760*890	1850*760* 890
6	Container loading qty  (40H)	247	185	148	112	98	80	65	56
