Bh8002 Brush Nickel 180 Degree Glass-to-Glass Standard Hinge

WALKER COMPANY LIMITED
  • Type：180°Hinge
  • Finish：Chrome Plated
  • General Finish：Chrome or Satin Nickel
  • Use：Glass
  • Packaging：Foam Bag and Box
  • Name：Glass Hinge

Base Info

  • Model NO.：BH8002
  • Place：Shower
  • Degree：180 Degree
  • Transport Package：Factory Standard Packing
  • Specification：SGS
  • Trademark：WALKER
  • Origin：China
  • HS Code：83021000
  • Production Capacity：50000PCS,Month

Description

Capacity36kgs(80lbs) / 2 hinges or 54kgs(120lbs) / 3 hingesGlass Thickness5/16" (8 mm) to 1/2" (12 mm) Tempered Safety GlassHinge Swings90 degree in and 90 degree OutClosing TypeSelf-Centering when within 15 degree of Closed PositionGasketBlack Rubber, Pvc, Asbestos is AvailableIncludesGaskets, Screws, and Glass Fabrication Dimensions

The Athena Series of professional Hinges is able to accommodate 5/16" (8 mm) to 1/2" (12 mm) glass.
Made of brass with all moving parts (pins and springs) in stainless steel.

Using two hinges with 5/16" to 1/2" glass (8 to 12 mm) the hinge will hold up to 80 lbs. (36 kg) with a maximum door width of 28" (711 mm).

Using three hinges with 5/16" to 1/2" glass (8 to 12 mm) the hinge will hold up to 120 lbs. (54 kg) with a maximum door width of 32" (813 mm).

135 Degree Glass-to-Glass Mount Model (Factory Set for Standard Closing Position)

Custom Finishes are Available on Request. Contact Walker Sales Department.

Attribute

Catalog NumberBH8002MaterialBrassColor (Finish)Chrome, Satin Nickel, Oil Rubbed Bronze and GoldSize96*76mmPackageStandard Export PackageShip ViaCan ship DHL, By sea and By airTestingSalt fog resistance for surface >/= 48 hours, Turning times of the spring: 50,000 times.Minimum Order1 Each (Special color:200 Nos)
