• Model NO.：SD468
• Temperature Type：Single-temperature
• Defrost Type：Auto Defrost
• Function：Cold Storage & Freezing, Cold Storage
• Certification：CE, RoHS, CB, SASO
• Refrigerant：R404A
• Compressor：Embraco
• Temperature Range：-18~-23 Celsius
• Voltage：220V,50Hz, 220V,60Hz, 110V,60Hz
• Color：White or Black
• Loading Qty：45PCS,40hq
• Cooling System：Ventilated Cooling
• Volume：468L
• Lighting：Vertical LED Tube
• Glass Door：Triple-Pane and Anti-Fog
• Transport Package：Wood Crate
• Specification：686*730*2000mm
• Trademark：SINCOOL
• Origin：China
• HS Code：8418500000
• Production Capacity：300PCS,Month

Basic Info.

Model NO. SD468 Temperature Type Single-temperature Defrost Type Auto Defrost Function Cold Storage & Freezing, Cold Storage Certification CE, RoHS, CB, SASO Refrigerant R404A Compressor Embraco Temperature Range -18~-23 Celsius Voltage 220V/50Hz, 220V/60Hz, 110V/60Hz Color White or Black Loading Qty 45PCS/40hq Cooling System Ventilated Cooling Volume 468L Lighting Vertical LED Tube Glass Door Triple-Pane and Anti-Fog Transport Package Wood Crate Specification 686*730*2000mm Trademark SINCOOL Origin China HS Code 8418500000 Production Capacity 300PCS/Month

Product Description

Commercial 468L Display Glass Door Refrigerated Freezer Showcase for Retail

Key Features:
⇒ Triple glazed thermal insulated anti fog heated glass door, providing maximum visibility to the frozen foods

⇒ Digital temperature control system provides precise and constant temperature.

⇒ Automatic evaporator fan motor delays

⇒ Interior vertical LED lighting for brilliant illumination and top branding canopy with LED backlit

⇒ Body structure is foamed with high-density PU (upto 40KG per m3)

⇒ 70mm ultra thick body insulation

⇒ Automatic defrosting with heating tubes

⇒ Defrosting water auto evaporated by hot gas from compressor, without the water drainage problem

⇒ Bottom mount compressor provides more efficient operation and easy access for maintenance and repair

⇒ 5PCS PVC coated adjustable heavy-duty steel wire shelves with price tags

⇒ White or Black Body Color, and stainless steel cabinet bottom is optional

How can we make the high-quality glass door freezers?

We have been making the upright glass door freezers since year 2013. We are well aware of that most of the problems on the glass door freezers are caused by the defrosting issue. We have well solved the defrosting issues from following aspects:
1. Ensure the freezer body is flat & smooth and glass door gasket is strong, so no leakage on the glass door. And all the holes on the freezer body are completely sealed.
2. Use the right power defrosting heater.
3. Install the defrosting water collection tray & water draining pipe with heating wires.
4. Evaporator fan motors are delayed to work after the defrosting ends.


Specifications:468

MODEL	SD468
CONDENSING UNIT TYPE	Plug-in Embraco
TEMPERATURE RANGE	-18°C ~ -23°C
AMBIENT TEMPERATURE	25°C
VOLTAGE	220V - 240V, 115V
FREQUENCY	50Hz, 60Hz
REFRIGERANT	R404a
PRODUCT DIMENSION (MM)	686(w) x 730(d) x 2000(h)
PACKING SIZE(MM)	746(W) X 790(d) x 2100(h)
LOADING QTY / 40HQ	45PCS

SD Plug-in Glass Door Freezer Series:

Model	Dimensions (MM)	Temerature Range	Volume	Compressor	Refrigeration Type	Loading Qty/40HQ
SD468	686*730*2000	-18~-23ºC / -10°F ~ 0°F	468L	Embraco	Fan Cooling, Plug-in	45PCS
SD958	1370*730*2000	-18~-23ºC / -10°F ~ 0°F	958L	Embraco	Fan Cooling, Plug-in	23PCS
SD1210	1830*730*2000	-18~-23ºC / -10°F ~ 0°F	1210L	Embraco	Fan Cooling, Plug-in	15PCS
SD1380	2025*730*2000	-18~-23ºC / -10°F ~ 0°F	1380L	Embraco	Fan Cooling, Plug-in	15PCS
